ELAUSYS NX-KNX NetworX Interface

ELAUSYS NX-KNX is a KNX gateway for the Caddx GE Interlogix NetworX alarm systems. It enables bidirectional communication with the alarm system using the RS232 serial port of the NetworX alarm system.

- KNX Interface for GE NetworX alarm systems (Caddx)
- Up to 96 zones status
- Control up to 4 areas (arm/partial/disarm)
- 9 status per area (alarm, entry, exit, fire,?)
- Recall of KNX scenes for each status
- Galvanic insulation from the KNX bus

DESCRIPTION
The KNX interface module NX-KNX is a KNX gateway for the GE Interlogix NetworX Caddx alarm systems. It enables bidirectional communication with the alarm system using the RS232 serial port of the alarm system.

It allows integrators to take advantage of a fully integrated alarm system including KNX scenarios, automatic lighting using the motion detectors, arming or monitoring the system using a KNX visualization.

This interface is intended to be used with a GE Interlogix NX series alarm system. The system must be equipped with a module for RS232 communication (for instance the NX-584E).
